7COJ

Crystal structure of the b-carbonic anhydrase CafA of the fungal pathogen Aspergillus fumigatus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.161
  • R-Value Observed: 0.163

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Crystal Structure of beta-Carbonic Anhydrase CafA from the Fungal Pathogen Aspergillus fumigatus .

Kim, S.Yeon, J.Sung, J.Jin, M.S.

(2020) Mol Cells 43: 831-840

  • DOI: https://doi.org/10.14348/molcells.2020.0168
  • Primary Citation of Related Structures:
    7COI, 7COJ

  • PubMed Abstract:

    The β-class of carbonic anhydrases (β-CAs) are zinc metalloenzymes widely distributed in the fungal kingdom that play essential roles in growth, survival, differentiation, and virulence by catalyzing the reversible interconversion of carbon dioxide (CO 2 ) and bicarbonate (HCO 3 - ). Herein, we report the biochemical and crystallographic characterization of the β-CA CafA from the fungal pathogen Aspergillus fumigatus , the main causative agent of invasive aspergillosis. CafA exhibited apparent in vitro CO 2 hydration activity in neutral to weak alkaline conditions, but little activity at acidic pH. The high-resolution crystal structure of CafA revealed a tetramer comprising a dimer of dimers, in which the catalytic zinc ion is tetrahedrally coordinated by three conserved residues (C119, H175, C178) and an acetate anion presumably acquired from the crystallization solution, indicating a freely accessible ″open″ conformation. Furthermore, knowledge of the structure of CafA in complex with the potent inhibitor acetazolamide, together with its functional intolerance of nitrate (NO 3 - ) ions, could be exploited to develop new antifungal agents for the treatment of invasive aspergillosis.


  • Organizational Affiliation

    School of Life Sciences, Gwangju Institute of Science and Technology (GIST), Gwangju 61005, Korea.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carbonic anhydrase
A, B, C, D
287Aspergillus fumigatus Af293Mutation(s): 0
Gene Names: AFUA_4G11250
EC: 4.2.1.1
UniProt
Find proteins for Q4WQ18 (Aspergillus fumigatus (strain ATCC MYA-4609 / CBS 101355 / FGSC A1100 / Af293))
Explore Q4WQ18
Go to UniProtKB:  Q4WQ18
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4WQ18
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
AZM (Subject of Investigation/LOI)
Query on AZM

Download Ideal Coordinates CCD File
F [auth A],
H [auth B],
J [auth C],
L [auth D]
5-ACETAMIDO-1,3,4-THIADIAZOLE-2-SULFONAMIDE
C4 H6 N4 O3 S2
BZKPWHYZMXOIDC-UHFFFAOYSA-N
ZN (Subject of Investigation/LOI)
Query on ZN

Download Ideal Coordinates CCD File
E [auth A],
G [auth B],
I [auth C],
K [auth D]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.161
  • R-Value Observed: 0.163
  • Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.921α = 90
b = 87.953β = 90
c = 144.717γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data scaling
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Research Foundation (NRF, Korea)Korea, Republic OfNRF-2017M3A9F6029753
National Research Foundation (NRF, Korea)Korea, Republic OfNRF-2019M3E5D6063908

Revision History  (Full details and data files)

  • Version 1.0: 2020-10-14
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Database references, Refinement description
