1O96

Structure of electron transferring flavoprotein for Methylophilus methylotrophus.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.212
  • R-Value Observed: 0.215

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Extensive Conformational Sampling in a Ternary Electron Transfer Complex.

Leys, D.Basran, J.Talfournier, F.Sutcliffe, M.J.Scrutton, N.S.

(2003) Nat Struct Biol 10: 219

  • DOI: https://doi.org/10.1038/nsb894
  • Primary Citation of Related Structures:
    1O94, 1O95, 1O96, 1O97

  • PubMed Abstract:

    Here we report the crystal structures of a ternary electron transfer complex showing extensive motion at the protein interface. This physiological complex comprises the iron-sulfur flavoprotein trimethylamine dehydrogenase and electron transferring flavoprotein (ETF) from Methylophilus methylotrophus. In addition, we report the crystal structure of free ETF. In the complex, electron density for the FAD domain of ETF is absent, indicating high mobility. Positions for the FAD domain are revealed by molecular dynamics simulation, consistent with crystal structures and kinetic data. A dual interaction of ETF with trimethylamine dehydrogenase provides for dynamical motion at the protein interface: one site acts as an anchor, thereby allowing the other site to sample a large range of interactions, some compatible with rapid electron transfer. This study establishes the role of conformational sampling in multi-domain redox systems, providing insight into electron transfer between ETFs and structurally distinct redox partners.


  • Organizational Affiliation

    Department of Biochemistry, University of Leicester, University Road, Leicester LE1 7RH, UK. dl37@le.ac.uk


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ELECTRON TRANSFERRING FLAVOPROTEIN BETA-SUBUNITA,
C,
E,
G [auth Q]
264Methylophilus methylotrophusMutation(s): 0
UniProt
Find proteins for P53570 (Methylophilus methylotrophus)
Explore P53570
Go to UniProtKB:  P53570
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53570
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
ELECTRON TRANSFERRING FLAVOPROTEIN ALPHA-SUBUNITB,
D,
F,
H [auth Z]
320Methylophilus methylotrophusMutation(s): 0
UniProt
Find proteins for P53571 (Methylophilus methylotrophus)
Explore P53571
Go to UniProtKB:  P53571
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53571
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FAD
Query on FAD

Download Ideal Coordinates CCD File
J [auth B],
L [auth D],
N [auth F],
P [auth Z]
FLAVIN-ADENINE DINUCLEOTIDE
C27 H33 N9 O15 P2
VWWQXMAJTJZDQX-UYBVJOGSSA-N
AMP
Query on AMP

Download Ideal Coordinates CCD File
I [auth A],
K [auth C],
M [auth E],
O [auth Q]
ADENOSINE MONOPHOSPHATE
C10 H14 N5 O7 P
UDMBCSSLTHHNCD-KQYNXXCUSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.212
  • R-Value Observed: 0.215
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 117.516α = 90
b = 126.877β = 90
c = 221.39γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-02-06
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-05-08
    Changes: Data collection, Database references, Other
