2P13 | pdb_00002p13

Transporter associated domain CorC_HlyC from Nitrosomonas europaea

• PDB DOI: https://doi.org/10.2210/pdb2P13/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Nitrosomonas europaea
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2007-03-01 Released: 2007-04-03
• Deposition Author(s): Kim, Y., Hatzos, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:
  0.243 (Depositor), 0.235 (DCC)
• R-Value Work:
  0.199 (Depositor), 0.195 (DCC)
• R-Value Observed:
  0.204 (Depositor)

Literature

The crystal structure of the transporter associated domain CorC_HlyC from Nitrosomonas europaea

Kim, Y., Hatzos, C., Clancy, S., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 20.43 kDa
• Atom Count: 1,655
• Modeled Residue Count: 168
• Deposited Residue Count: 180
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CBS domain	A, B	90	Nitrosomonas europaea	Mutation(s): 1  Gene Names: NE2227
UniProt
Find proteins for Q82SS8 (Nitrosomonas europaea (strain ATCC 19718 / CIP 103999 / KCTC 2705 / NBRC 14298)) Explore Q82SS8  Go to UniProtKB:  Q82SS8

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ACY	C [auth A]	ACETIC ACID C2 H4 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.65 Å
• R-Value Free:  0.243 (Depositor), 0.235 (DCC)
• R-Value Work:  0.199 (Depositor), 0.195 (DCC)
• R-Value Observed: 0.204 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.397	α = 90
b = 49.397	β = 90
c = 127.094	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-3000	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXCD	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
SOLVE	phasing
RESOLVE	phasing
PHENIX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-04-03
Deposition Author(s): Kim, Y., Hatzos, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2007-04-03
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.3: 2017-10-18
  Changes: Refinement description
• Version 1.4: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
