4TS3

Wild type E. Coli purine nucleoside phosphorylase with 2 FMC molecules in active sites


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.176
  • R-Value Observed: 0.179

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Crystallographic snapshots of ligand binding to hexameric purine nucleoside phosphorylase and kinetic studies give insight into the mechanism of catalysis.

Stefanic, Z.Narczyk, M.Mikleusevic, G.Kazazic, S.Bzowska, A.Luic, M.

(2018) Sci Rep 8: 15427-15427

  • DOI: https://doi.org/10.1038/s41598-018-33723-1
  • Primary Citation of Related Structures:
    4TS3, 4TS9, 4TTA, 4TTI, 4TTJ

  • PubMed Abstract:

    Purine nucleoside phosphorylase (PNP) catalyses the cleavage of the glycosidic bond of purine nucleosides using phosphate instead of water as a second substrate. PNP from Escherichia coli is a homohexamer, build as a trimer of dimers, and each subunit can be in two conformations, open or closed. This conformational change is induced by the presence of phosphate substrate, and very likely a required step for the catalysis. Closing one active site strongly affects the others, by a yet unclear mechanism and order of events. Kinetic and ligand binding studies show strong negative cooperativity between subunits. Here, for the first time, we managed to monitor the sequence of nucleoside binding to individual subunits in the crystal structures of the wild-type enzyme, showing that first the closed sites, not the open ones, are occupied by the nucleoside. However, two mutations within the active site, Asp204Ala/Arg217Ala, are enough not only to significantly reduce the effectiveness of the enzyme, but also reverse the sequence of the nucleoside binding. In the mutant the open sites, neighbours in a dimer of those in the closed conformation, are occupied as first. This demonstrates how important for the effective catalysis of Escherichia coli PNP is proper subunit cooperation.


  • Organizational Affiliation

    Division of Physical Chemistry, Ruđer Bošković Institute, Bijenička 54, Zagreb, 10000, Croatia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Purine nucleoside phosphorylase DeoD-type
A, B, C, D, E
A, B, C, D, E, F
237Escherichia coliMutation(s): 0
EC: 2.4.2.1
UniProt
Find proteins for P0ABP8 (Escherichia coli (strain K12))
Explore P0ABP8
Go to UniProtKB:  P0ABP8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ABP8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FMC
Query on FMC

Download Ideal Coordinates CCD File
G [auth A],
N [auth F]
(1S)-1-(7-amino-1H-pyrazolo[4,3-d]pyrimidin-3-yl)-1,4-anhydro-D-ribitol
C10 H13 N5 O4
KBHMEHLJSZMEMI-KSYZLYKTSA-N
PO4
Query on PO4

Download Ideal Coordinates CCD File
H [auth A]
I [auth B]
J [auth C]
K [auth D]
L [auth E]
H [auth A],
I [auth B],
J [auth C],
K [auth D],
L [auth E],
M [auth F]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.176
  • R-Value Observed: 0.179
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 61.921α = 90
b = 123.373β = 90
c = 189.051γ = 90
Software Package:
Software NamePurpose
SCALAdata scaling
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-07-08
    Type: Initial release
  • Version 1.1: 2018-10-31
    Changes: Advisory, Data collection, Database references
  • Version 1.2: 2024-05-08
    Changes: Advisory, Data collection, Database references
