6QX4

Structure of the Bacillus anthracis Sap S-layer assembly domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.27 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.173
  • R-Value Observed: 0.175

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structure of S-layer protein Sap reveals a mechanism for therapeutic intervention in anthrax.

Fioravanti, A.Van Hauwermeiren, F.Van der Verren, S.E.Jonckheere, W.Goncalves, A.Pardon, E.Steyaert, J.De Greve, H.Lamkanfi, M.Remaut, H.

(2019) Nat Microbiol 4: 1805-1814

  • DOI: https://doi.org/10.1038/s41564-019-0499-1
  • Primary Citation of Related Structures:
    6HHU, 6QX4

  • PubMed Abstract:

    Anthrax is an ancient and deadly disease caused by the spore-forming bacterial pathogen Bacillus anthracis. At present, anthrax mostly affects wildlife and livestock, although it remains a concern for human public health-primarily for people who handle contaminated animal products and as a bioterrorism threat due to the high resilience of spores, a high fatality rate of cases and the lack of a civilian vaccination programme 1,2 . The cell surface of B. anthracis is covered by a protective paracrystalline monolayer-known as surface layer or S-layer-that is composed of the S-layer proteins Sap or EA1. Here, we generate nanobodies to inhibit the self-assembly of Sap, determine the structure of the Sap S-layer assembly domain (Sap AD ) and show that the disintegration of the S-layer attenuates the growth of B. anthracis and the pathology of anthrax in vivo. Sap AD comprises six β-sandwich domains that fold and support the formation of S-layers independently of calcium. Sap-inhibitory nanobodies prevented the assembly of Sap and depolymerized existing Sap S-layers in vitro. In vivo, nanobody-mediated disruption of the Sap S-layer resulted in severe morphological defects and attenuated bacterial growth. Subcutaneous delivery of Sap inhibitory nanobodies cleared B. anthracis infection and prevented lethality in a mouse model of anthrax disease. These findings highlight disruption of S-layer integrity as a mechanism that has therapeutic potential in S-layer-carrying pathogens.


  • Organizational Affiliation

    Structural and Molecular Microbiology, Structural Biology Research Center, VIB, Brussels, Belgium. antonella.fioravanti@vub.be.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
S-layer protein sap
A, B
606Bacillus anthracisMutation(s): 0
Gene Names: sapBA_0885GBAA_0885BAS0841
UniProt
Find proteins for P49051 (Bacillus anthracis)
Explore P49051
Go to UniProtKB:  P49051
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49051
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Nanobody NbAF683
C, E
129Lama glamaMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Nanobody NbAF694D,
F [auth H]
134Lama glamaMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.27 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.173
  • R-Value Observed: 0.175
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.23α = 88.66
b = 79.91β = 82
c = 81.23γ = 85.59
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
autoPROCdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Research Foundation - FlandersBelgiumG028113N

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-31
    Type: Initial release
  • Version 1.1: 2019-11-06
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-11-06
    Changes: Structure summary
