1ZWY | pdb_00001zwy

Crystal structure of protein VC0702 from Vibrio cholerae

• PDB DOI: https://doi.org/10.2210/pdb1ZWY/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Vibrio cholerae
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2005-06-06 Released: 2005-07-19
• Deposition Author(s): Chang, C., Wu, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.226 (Depositor), 0.235 (DCC)
• R-Value Work:
  0.180 (Depositor), 0.195 (DCC)
• R-Value Observed:
  0.183 (Depositor)

Literature

Crystal structure of protein VC0702 from Vibrio cholerae

Chang, C., Wu, R., Moy, S., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PQS (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 84.22 kDa
• Atom Count: 6,062
• Modeled Residue Count: 690
• Deposited Residue Count: 740
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical UPF0244 protein VC0702	A, B, C, D	185	Vibrio cholerae	Mutation(s): 6  EC: 3.6.1.73
UniProt
Find proteins for Q9KU27 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)) Explore Q9KU27  Go to UniProtKB:  Q9KU27

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.226 (Depositor), 0.235 (DCC)
• R-Value Work:  0.180 (Depositor), 0.195 (DCC)
• R-Value Observed: 0.183 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.399	α = 90
b = 105.347	β = 104.57
c = 75.272	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
DM	phasing
SOLVE	phasing
RESOLVE	phasing
O	model building
Coot	model building
CCP4	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2005-07-19
Deposition Author(s): Chang, C., Wu, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2005-07-19
  Type: Initial release

• Version 1.1: 2008-04-30
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Derived calculations, Version format compliance
• Version 1.3: 2018-01-31
  Changes: Experimental preparation
• Version 1.4: 2024-10-16
  Changes: Data collection, Database references, Derived calculations, Structure summary
