3L34 | pdb_00003l34

The crystal structure of a two-component sensor domain (2nd form) from Pseudomonas aeruginosa PA01

• PDB DOI: https://doi.org/10.2210/pdb3L34/pdb

• Classification: TRANSFERASE
• Organism(s): Pseudomonas aeruginosa PAO1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-12-16 Released: 2010-01-12
• Deposition Author(s): Tan, K., Chhor, G., Buck, K., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free:
  0.225 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.182 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.184 (Depositor)

Starting Model: experimental

Literature

The crystal structure of a two-component sensor domain from Pseudomonas aeruginosa PA01

Tan, K., Chhor, G., Buck, K., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 generated by PISA (software)

Biological Assembly 4

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 4 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 116.46 kDa
• Atom Count: 8,232
• Modeled Residue Count: 965
• Deposited Residue Count: 1,040
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sensor protein	A, B, C, D, E, F, G, H	130	Pseudomonas aeruginosa PAO1	Mutation(s): 0  Gene Names: PA5484, Pseudomonas aeruginosa EC: 2.7.13.3
UniProt
Find proteins for Q9HT87 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9HT87  Go to UniProtKB:  Q9HT87

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D, E, F, G, H	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free:  0.225 (Depositor), 0.220 (DCC)
• R-Value Work:  0.182 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.184 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.506	α = 90
b = 103.081	β = 90.01
c = 69.465	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-01-12
Deposition Author(s): Tan, K., Chhor, G., Buck, K., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2010-01-12
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2023-09-06
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 1.3: 2023-11-22
  Changes: Data collection
• Version 1.4: 2024-11-20
  Changes: Structure summary
