4GVA | pdb_00004gva

ADP-bound form of the ERK2 kinase

• PDB DOI: https://doi.org/10.2210/pdb4GVA/pdb

• Classification: TRANSFERASE
• Organism(s): Rattus norvegicus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2012-08-30 Released: 2012-09-12
• Deposition Author(s): Pozharski, E., Zhang, J., Shapiro, P.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.83 Å
• R-Value Free:
  0.241 (Depositor), 0.238 (DCC)
• R-Value Work:
  0.189 (Depositor), 0.188 (DCC)
• R-Value Observed:
  0.191 (Depositor)

Literature

ADP-bound form of the ERK2 kinase

Zhang, J., Shapiro, P., Pozharski, E.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 42.75 kDa
• Atom Count: 3,051
• Modelled Residue Count: 346
• Deposited Residue Count: 364
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 1	A	364	Rattus norvegicus	Mutation(s): 0  Gene Names: Mapk1, Erk2, Mapk, Prkm1 EC: 2.7.11.24
UniProt
Find proteins for P63086 (Rattus norvegicus) Explore P63086  Go to UniProtKB:  P63086

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ADP	B [auth A]	ADENOSINE-5'-DIPHOSPHATE C10 H15 N5 O10 P2 XTWYTFMLZFPYCI-KQYNXXCUSA-N
GOL	C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CME	A	L-PEPTIDE LINKING	C5 H11 N O3 S2		CYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.83 Å
• R-Value Free:  0.241 (Depositor), 0.238 (DCC)
• R-Value Work:  0.189 (Depositor), 0.188 (DCC)
• R-Value Observed: 0.191 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.605	α = 90
b = 69.072	β = 108.49
c = 59.962	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XSCALE	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-09-12
Deposition Author(s): Pozharski, E., Zhang, J., Shapiro, P.

Revision History

• Version 1.0: 2012-09-12
  Type: Initial release

• Version 1.1: 2024-11-27
  Changes: Data collection, Database references, Derived calculations, Structure summary
