4TXK | pdb_00004txk

Construct of MICAL-1 containing the monooxygenase and calponin homology domains

• PDB DOI: https://doi.org/10.2210/pdb4TXK/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Mus musculus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2014-07-03 Released: 2015-12-23
• Deposition Author(s): Alqassim, S.S., Amzel, L.M., Bianchet, M.A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.88 Å
• R-Value Free:
  0.272 (Depositor), 0.270 (DCC)
• R-Value Work:
  0.203 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.206 (Depositor)

Literature

Structural insights into modulation of MICAL activity by its Calponin Homology (CH) domain

Alqassim, S.S., Amzel, L.M., Bianchet, M.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 68.49 kDa
• Atom Count: 4,608
• Modeled Residue Count: 581
• Deposited Residue Count: 615
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein-methionine sulfoxide oxidase MICAL1	A	615	Mus musculus	Mutation(s): 0  Gene Names: Mical1, Mical, Nical EC: 1.14.13 (PDB Primary Data), 1.6.3.1 (UniProt), 1.14.13.225 (UniProt)
UniProt
Find proteins for Q8VDP3 (Mus musculus) Explore Q8VDP3  Go to UniProtKB:  Q8VDP3

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FAD	C [auth A]	FLAVIN-ADENINE DINUCLEOTIDE C27 H33 N9 O15 P2 VWWQXMAJTJZDQX-UYBVJOGSSA-N
PEG	B [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.88 Å
• R-Value Free:  0.272 (Depositor), 0.270 (DCC)
• R-Value Work:  0.203 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.206 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.233	α = 90
b = 50.174	β = 101.16
c = 96.966	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
MOLREP	phasing
Coot	model building
PDB_EXTRACT	data extraction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2015-12-23
Deposition Author(s): Alqassim, S.S., Amzel, L.M., Bianchet, M.A.

Revision History

• Version 1.0: 2015-12-23
  Type: Initial release

• Version 1.1: 2016-07-27
  Changes: Data collection
• Version 1.2: 2023-12-27
  Changes: Data collection, Database references, Derived calculations
