8S7N | pdb_00008s7n

Vanillyl-alcohol dehydrogenase from Marinicaulis flavus: P151L mutant bound to eugenol


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.184 (Depositor), 0.195 (DCC)
  • R-Value Work:
    0.158 (Depositor), 0.170 (DCC)
  • R-Value Observed:
    0.159 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted EOLClick on this verticalbar to view details

This is version 1.2 of the entry. See complete history


Literature

Dehydrogenase versus oxidase function: the interplay between substrate binding and flavin microenvironment.

Guerriere, T.B.Vancheri, A.Ricotti, I.Serapian, S.A.Eggerichs, D.Tischler, D.Colombo, G.Mascotti, M.L.Fraaije, M.W.Mattevi, A.

(2025) ACS Catal 15: 1046-1060

  • DOI: https://doi.org/10.1021/acscatal.4c05944
  • Primary Citation of Related Structures:
    8S7N, 8S7P, 8S7Q, 8S7R, 8S7S, 8S7T, 8S7U, 8S7W, 9FFK, 9FGE

  • PubMed Abstract:

    Redox enzymes, mostly equipped with metal or organic cofactors, can vary their reactivity with oxygen by orders of magnitudes. Understanding how oxygen reactivity is controlled by the protein milieu remains an open issue with broad implications for mechanistic enzymology and enzyme design. Here, we address this problem by focusing on a widespread group of flavoenzymes that oxidize phenolic compounds derived from microbial lignin degradation, using either oxygen or a cytochrome c as electron acceptors. A comprehensive phylogenetic analysis revealed conserved amino acid motifs in their flavin-binding site. Using a combination of kinetics, mutagenesis, structural, and computational methods, we examined the role of these residues. Our results demonstrate that subtle and localized changes in the flavin environment can drastically impact on oxygen reactivity. These effects are afforded through the creation or blockade of pathways for oxygen diffusion. Substrate binding plays a crucial role by potentially obstructing oxygen access to the flavin, thus influencing the enzyme's reactivity. The switch between oxidase and dehydrogenase functionalities is thereby achieved through targeted, site-specific amino acid replacements that finely tune the microenvironment around the flavin. Our findings explain how very similar enzymes can exhibit distinct functional properties, operating as oxidases or dehydrogenases. They further provide valuable insights for the rational design and engineering of enzymes with tailored functions.


  • Organizational Affiliation

    Department of Biology and Biotechnology "Lazzaro Spallanzani", University of Pavia, Pavia, Italy 27100.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Oxidoreductase
A, B
521Marinicaulis flavusMutation(s): 1
Gene Names: CW354_13745
UniProt
Find proteins for A0A2S7K3M2 (Marinicaulis flavus)
Explore A0A2S7K3M2
Go to UniProtKB:  A0A2S7K3M2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2S7K3M2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FAD
Query on FAD

Download Ideal Coordinates CCD File
C [auth A],
N [auth B]
FLAVIN-ADENINE DINUCLEOTIDE
C27 H33 N9 O15 P2
VWWQXMAJTJZDQX-UYBVJOGSSA-N
PE4
Query on PE4

Download Ideal Coordinates CCD File
H [auth A]2-{2-[2-(2-{2-[2-(2-ETHOXY-ETHOXY)-ETHOXY]-ETHOXY}-ETHOXY)-ETHOXY]-ETHOXY}-ETHANOL
C16 H34 O8
PJWQOENWHPEPKI-UHFFFAOYSA-N
1PE
Query on 1PE

Download Ideal Coordinates CCD File
G [auth A],
S [auth B]
PENTAETHYLENE GLYCOL
C10 H22 O6
JLFNLZLINWHATN-UHFFFAOYSA-N
EOL (Subject of Investigation/LOI)
Query on EOL

Download Ideal Coordinates CCD File
K [auth A],
T [auth B]
2-methoxy-4-(prop-2-en-1-yl)phenol
C10 H12 O2
RRAFCDWBNXTKKO-UHFFFAOYSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
F [auth A],
J [auth A],
R [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
NO3
Query on NO3

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
I [auth A]
L [auth A]
M [auth B]
NITRATE ION
N O3
NHNBFGGVMKEFGY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.184 (Depositor), 0.195 (DCC)
  • R-Value Work:  0.158 (Depositor), 0.170 (DCC)
  • R-Value Observed: 0.159 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 139.019α = 90
b = 139.019β = 90
c = 181.059γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted EOLClick on this verticalbar to view details

Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European CommissionEuropean UnionB-Ligzymes (GA 824017)

Revision History  (Full details and data files)

  • Version 1.0: 2025-01-15
    Type: Initial release
  • Version 1.1: 2025-01-22
    Changes: Database references
  • Version 1.2: 2025-02-05
    Changes: Database references
