8RIF | pdb_00008rif

Cryo-EM structure of the MCM double hexamer loaded onto dsDNA.

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.79 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history.


Literature

Inhibition of Origin Recognition Complex by Cyclin Dependent Kinase Reveals Alternate Mechanism of MCM Loading

Miller, T.C.R., Lim, C.T., Diffley, J.F.X., Costa, A.

To be published.

Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM2A [auth 2],
I [auth A]		868Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM2, YBL023C, YBL0438
EC: 3.6.4.12
UniProt
Find proteins for P29469 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P29469
Go to UniProtKB:  P29469
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP29469
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM3B [auth 3],
J [auth B]		1,006Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM3, YEL032W, SYGP-ORF23
EC: 3.6.4.12
UniProt
Find proteins for P24279 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P24279
Go to UniProtKB:  P24279
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP24279
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM4C [auth 4],
K [auth C]		933Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM4, CDC54, HCD21, YPR019W, YP9531.13
EC: 3.6.4.12
UniProt
Find proteins for P30665 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P30665
Go to UniProtKB:  P30665
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP30665
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Minichromosome maintenance protein 5D [auth 5],
L [auth D]		775Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM5, CDC46, YLR274W, L9328.1
EC: 3.6.4.12
UniProt
Find proteins for P29496 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P29496
Go to UniProtKB:  P29496
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP29496
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM6E [auth 6],
M [auth E]		1,017Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM6, YGL201C
EC: 3.6.4.12
UniProt
Find proteins for P53091 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53091
Go to UniProtKB:  P53091
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53091
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM7F [auth 7],
N [auth F]		845Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM7, CDC47, YBR202W, YBR1441
EC: 3.6.4.12
UniProt
Find proteins for P38132 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38132
Go to UniProtKB:  P38132
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38132
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP (Subject of Investigation/LOI)
Query on ATP
Download Ideal Coordinates CCD File
BA [auth A],
O [auth 2]		ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
ADP (Subject of Investigation/LOI)
Query on ADP
Download Ideal Coordinates CCD File
EA [auth B]
HA [auth D]
LA [auth F]
R [auth 3]
U [auth 5]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
ZN (Subject of Investigation/LOI)
Query on ZN
Download Ideal Coordinates CCD File
AA [auth 7]
DA [auth A]
GA [auth C]
JA [auth D]
KA [auth E]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG (Subject of Investigation/LOI)
Query on MG
Download Ideal Coordinates CCD File
CA [auth A]
FA [auth B]
IA [auth D]
MA [auth F]
P [auth 2]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.79 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1
MODEL REFINEMENTPHENIX1.19.2_4158:

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Wellcome TrustUnited KingdomFC001065
Medical Research Council (MRC, United Kingdom)United KingdomFC001065
Cancer Research UKUnited KingdomFC001065
European Research Council (ERC)European Union820102
Novo Nordisk FoundationDenmarkNNF22OC0073571
Danish National Research FoundationDenmarkDNRF115

Revision History  (Full details and data files)

  • Version 1.0: 2025-01-01
    Type: Initial release
